How to Install Air Curtain on door?

Select the Right Air Curtain

• Choose an air curtain appropriate for your door's width, height, and purpose (e.g., heating, cooling, dust or insect barrier).

Prepare the Installation Area

• Clear the doorway area and ensure no obstructions will interfere with the installation.

Measure and Mark the Mounting Position

• Measure the width of the door and find the center.

• Mark the mounting holes on the wall or door frame above the doorway, ensuring the air curtain will be aligned properly with the door’s center.

• Placement Height: The air curtain should ideally be mounted 2-3 inches above the door frame for maximum efficiency.

Drill Holes for Mounting

• Use a drill to make holes at the marked points.

• Install wall plugs if mounting on a masonry or concrete surface.

Attach the Mounting Bracket

• If the air curtain comes with a mounting bracket, secure the bracket to the wall using screws. Use a level to ensure the bracket is straight.

Mount the Air Curtain

• Lift the air curtain unit and secure it onto the bracket or directly onto the wall using screws.

• Double-check that the unit is securely fastened and level.

Electrical Connection

• Plug-in Model: Simply plug the unit into a nearby power outlet.

• Hardwired Model: Turn off the power at the circuit breaker. Connect the unit to the electrical system following the manufacturer’s wiring diagram. If unsure, consult a professional electrician for this step.

Test the Unit

• Turn on the air curtain and test its operation.

• Ensure the airflow covers the entire doorway width and creates an invisible barrier when the door is open.

Adjust Settings

• Adjust the speed and temperature (if applicable) based on your requirements.

Finalize the Installation

• Clean up the area, and ensure all screws and wiring are secure.

• Regularly check for maintenance needs like filter cleaning or fan adjustments.
